Tuff Rib
Metal Panel
The Tuff Rib panel is a durable and economical, exposed-fastener metal panel with a classic ribbed profile. It provides reliable performance for both roofing and siding applications and is available in a variety pf colors.
Tuff Rib panels are one of the most popular choices for homes, garages, shops, barns, and agricultural buildings. The proven ribbed design provides dependable strength while keeping installation straightforward and cost-effective. Contractors and DIY builders appreciate its versatility, wide color selection, and ability to create a clean, professional metal roof or siding system that performs well for decades.
Panel Profile
The Tuff Rib panel features a low rib height with evenly spaced ribs that add strength and help direct water off the roof. This exposed-fastener profile provides excellent versatility for roofing and siding on homes, shops, barns, and outbuildings.
Tuff Rib Panel Specifications
Coverage Width
36 inches
Ideal Applications
Rib Height
3/4 inch
major rib every 9" oc
- Residential homes
- Garages
- Shops
- Barns
- Agricultural buildings
- Wainscoting
- Metal siding applications
Fastener Type
Exposed fastener
Standard Gauges
29 gauge
Optional Gauge
26 gauge (available by request)
Recommended Minimum Roof Pitch
3:12
Panel Lengths Available
Custom cut to length
Tuff Rib Installation Examples
Tuff Rib panels are used on a wide range of building types including homes, garages, barns, shops, and agricultural structures. Below are examples of finished roofing and siding projects using Tuff Rib panels.
Tuff Rib siding, soffit, and roof installed on a shop house.
Shop with Ash Gray Tuff Rib metal siding.
Durable Tuff Rib siding on an agricultural barn.
Dark BrownTuff Rib roofing on a classic residential home.
Dark Gray Tuff Rib roof with covered patio.
Available Color Options
Tuff Rib panels are available in a wide range of durable painted finishes designed to provide long-lasting protection and attractive appearance.
SMP COLOR CHART
FOR 29 GA
SMP paint systems are developed using a blend of polyester and silicone agents. Silicone acts to improve the gloss retention and weather resistance of the polyester coating. SMP pre-painted steel has been used for decades and is preferred by many building owners due to the relative durability of the coating and the budget-friendly cost as compared to other more expensive paint systems.
Contact us for current availability and more options.
*Certain colors may be subject to an order minimum and longer lead time.
Ridge Cap
Covers the peak of the roof to help shed water off both sides.
Valley Trim
Channels water safely down roof valleys where two slopes meet.
Recommended Trim for Tuff Rib Panels
Trim components complete the roof system and help protect edges and transitions from water intrusion. Proper trim also enhances the finished appearance of the roof.
Gable Trim
Finishes and protects the exposed edges along the gable ends.
Sidewall Flashing
Seals the joint where the roof meets a vertical sidewall.
Eave Trim
Guides water away from the eaves and protects the roof edge.
Endwall Flashing
Protects the transition where the roof runs into an upper wall.
Metal Roofing Screws
Color-matched fasteners with sealing washers for a weather-tight connection.
Installation Accessories
Closure Strips
Venting and non-venting closures that are profile matched to fir at trim and panel transitions.
Using the correct fasteners and accessories helps ensure proper installation and long-term roof performance.
Butyl Tape
High-tack sealant tape used at panel laps and critical seams.
Underlayment
Synthetic. High-Temp. Non-Granular. A crucial layer that provides additional protection against moisture and weather elements.
Pipe Boots
Form-fitting flashing for sealing around pipes and round penetrations. High Temp and EPDM
